Any of the AFS screens can be configured as an EFIS , Engine Monitor or both if hardware modules are installed in the same screen. Connect an EFIS screen with an Engine Monitor screen using the Advanced Avionics Bus and you can display the EFIS, Engine Monitor, or both on either screen. You can even connect an EFIS/Engine Monitor screen with an EFIS screen giving you a system with multiple Attitude Heading Reference Systems (AHRS). The optional Angle-Of-Attack module can be added to the screen giving you our superior and proven AOA technology on the EFIS display.

Weights and Balance AF-5000 series display feature

Weight & Balance

Instantly calculate your CG and load with our Weight and Balance page.
Analog Instruments AF-5000 series display feature

Analog Instruments

Standard Analog 6-Pack Instrument display; including - analog HSI.
Airport and Airspace Information AF-5000 series display feature

Airport/Airspace Information

Complete airport information; including - runways, frequencies, METAR's, TAF's and pattern altitudes. Selectable airspace information; including - highlight current boundaries and display the vertical limits. Lets you easily select and display overlapping complicated airspaces, reducing pilot workload.
Approach plates, VFR Sectionals and IFR charts AF-5000 series display feature

Approach Plates, VFR Sectionals & IFR Charts

Geo-Referenced Approach Plates, Sectionals and IFR Low Charts display your aircraft's current location, as well as traffic. Updated every 28 days, display in full-screen or split-screen mode.
Emergency Glide AF-5000 series display feature

EMERGENCY Glide

Calculates and displays airports that are within your aircraft's engine-out glide range.
GPS and ILS AF-5000 series display feature

GPS and ILS Display

CDI and VDI displayed from external GPS navigator or Nav radio.
Aircraft Maintenance Logs AF-5000 series display feature

Aircraft Maintenance Logs

Keeps track and alerts you when it's time for Oil Changes, Annual Inspections, ELT Batteries, Filters, Brakes or any other user configurable item.
Flight Planning AF-5000 series display feature

Flight Planning

Loads multi-leg flight plan from an external GPS navigator or allows user input from EFIS Screen.
Channel selection and volume control all conveniently accessible from and screen in the aircraft.

XM Radio

Channel selection and volume control all conveniently accessible from and screen in the aircraft.
Weather/Traffic is optional, and requires a XM receiver module or Navworx ADS-B Receiver.

Weather and Traffic

Our ADVANCED Weather/Traffic is optional, and requires a XM receiver module or Navworx ADS-B Receiver. Enables a live NEXRAD, METAR, TFR, Wind aloft, and Traffic.
Draw a image to the specifications outlined in the manual to have your own aircraft or image displayed on your maps and charts.

Custom Map Airplane

Draw a image to the specifications outlined in the manual to have your own aircraft or image displayed on your maps and charts.
Flight Planning AF-5000 series display feature

Geo-Referenced Data

Geo-Referenced will display your aircraft's location as well as the location of surrounding traffic on all maps, charts, and airport diagrams.

Engine Monitoring Features

  • Fuel Gauges: Support for up to four fuel tanks, all with low-level voice alerts.
  • Fuel Computer: Full-feature fuel computer includes Gallons used, Gallons remaining, MPG and Gallons remaining at waypoint.
  • Flap & Trim Positions: Directly reads most popular trim motors.
  • Active Checklists: Multiple user configurable checklists.
  • Voice Alerts: The system will warn you if any instrument enters the warning range. Other systems use low tech beeps as warnings.
  • Dual Bus Support: Displays Dual Voltage and Dual Alternator outputs.
  • Flight Timers: Count-Up and Count-Down timers.
  • Data Logging: Easily transfer over 50 hours of stored data to your PC using the convenient SD data card.
  • Tach and Hobbs: Records both Tach and Hobbs times.
  • Turbine Engine Support: Custom engine display for turbine engines.
  • EGT and CHT Display: Displays all six CHT and EGT temperatures at the same time.
  • Lean Mode: Detects and displays each cylinder as it peaks for LOP or ROP operation. Displays the degrees from peak along with current rich or lean status.

Other Features

  • Landing Gear Warning: The Pilot will be prompted to check landing gear if the gear is down at a set high airspeed, or up at a set low airspeed. Amphibious aircraft are prompted to select "Runway" or "Water" and are then given audible wordings depending on the position of the landing gear.
  • Voice Alerts: All of our systems have a full-featured voice alert system. Lose oil pressure, for instance, and you will immediately hear “Check Oil Pressure.”
  • Digital Inputs: Can be used for door warnings, landing gear, or any number of user configurable switches.
  • Touch Screen: The AF-5000 Touch Screen option adds flexibility, capability, and a more intuitive user experience while retaining the full functionality of physical buttons, knobs, and a joystick. Fly into weather with the confidence of redundancy.
  • EFIS HSI Truly WAAS Compatible: Our display integrates aircraft heading with GPS, VOR, Localizer and Glide Slope information. Garmin’s new WAAS enabled 430 has substantially different software from non-WAAS 430 units. AFS has performed numerous actual ILS and LPV approaches to verify that our 430W interface truly works, including the ability to send OBS Course and heading data from the EFIS back to the 430W.
  • Remote Radio Tuning: Tune your SL30 or AFS Comm Radio Remotely from any EFIS Screen.
  • Vertical Power VP-X Integration: The AF-5000 series systems are capable of interfacing to the VP-X electronic circuit breaker power system. Electrical Systems can be accessed and control through the VP-X page.
